1.06 Inch TN TFT LCD Module 96x160 RGB SPI Display

1.06 Inch TN TFT LCD Module 96x160 RGB SPI Display

1.06 Inch TN TFT LCD Module 96x160 RGB SPI Display
1.06 Inch TN TFT LCD Module 96x160 RGB SPI Display
Categories TFT LCD Display Panel
Place of Origin: Guangdong, China
Brand Name: Genyu
MOQ: 1000
Price: $1.15-1.45
Display Size: 1.06 inch
Display Type: TN
Resolution: 96xRGBx160 Dots
Module Size: 16.12(H)*29.76(V)*1.52(D) mm
Active Area: 13.82(H)*23.04(V) mm
Pixel Pitch: 48(H)*3*144(V) μm
Pixel Arrangement: RGB stripe
Driver IC: ST7735S
Interface: 4 SPI
Operating Temperature: -20~+70℃
Storage Temperature: -30~+80℃
Display Mode: Normally White
Number of Colors: 262K
Luminance: 250 cd/m2
Contrast Ratio: 500
Contact Now
Company Info.
Shenzhen Genyu Optical Co., Ltd.
Verified Supplier
View Contact Details
Product List
  • Haven't found right suppliers
  • Our buyer assistants can help you find the most suitable, 100% reliable suppliers from China.
  • And this service is free of charge.
  • we have buyer assistants who speak English, French, Spanish......and we are ready to help you anytime!
Submit Buying Request
  • Product Details
  • Company Profile

1.06 Inch TN TFT LCD Module 96x160 RGB SPI Display

1.06 Inch 96 RGBx160 Dots Thin Small TN Screen Display 13 Pins Soldering Type 4SPI TFT LCD Module

Product Description

A. 1.06 inch TFT LCD Parameters:


ItemSpecificationUnit
Module Size16.12(H)*29.76(V)*1.52(D)mm
Panel Active Area13.82(W)*23.04(H)mm
Pixel Pitch48(H)*3*144(V)μm
Pixel ArrangementRGB stripe
WeightTBDg
Driver ICST7735S
Light Source1 white led, 20mA
Interface4 SPI
Operating Temperature-20~+70℃
Storage Temperature-30~+80℃
Panel TypeTN
Resolution96xRGBx160 Dotspixel
Display ModeNormally White
Number of Colors262K
Luminance250cd/m2
Contrast Ratio500
Viewing Angle3/6/9/12 O'clock, IPS


B. 1.0 inch TFT LCD Screen:



C. 0.96 Inch TFT LCD Display:


Similar Products

D. More Dot Matrix LCD Display maybe you will like:


Company Information
Why Choose Us?
Whatever you need we'll be able to meet it, such as the following:
  • a) Own COG, COB, LCD Backlight Production Lines, Competitive Price Accepted;
  • b) Solid and Reliable R&D Team, Free Technical Support Provided;
  • c) Double 100% Test/Inspection Before Shipping, Quality Guaranteed;
  • d) Fast Leading Time, Cheap Freight/Transportation Fee;
  • e) Good After Sales Services in 24 Hours.
  • f) The Warranty Period of the Products is Usually 12 Months.
Packaging & Shipping

Payment
T/T, Western Union. Paypal and etc...

Delivery
Items will be shipped within 3 working days after payment is received.


By DHL/UPS/FedEx: about 5-7 working days.
By EMS/POSTNL: about 15-20 working days.

Packaging

1. Electrostatic Bag/ Anti-static Trays/ Plastic Pallet/ Air Bubble Film...

2. Suitable Carton Boxes.

The packing is able to withstand rough handling.


FAQ1
1. Q: Are you a manufactory or trade company?
A. We are a factory located in Shenzhen and Jiangxi, which specializes in TN, HTN, STN, FSTN, VA monochrome LCD, Micro OLED Screen, Color TFT Display Panels, LED Backlights, and LCD Modules.
2. Q: Will you offer a free sample?
A: For the first cooperation, samples will be charged, and the amount will be returned at the mass order stage.
In regular cooperation, samples can be free.
3. Q: What is the delivery time?
A: For sample order: 2-3 weeks. For mass production: 4-6 weeks.
4. Q: Can you custom the LCD or touch screen for me?
A: Yes, we can provide custom services.
For the LCD display, backlight brightness and FPC cable can be customized.
For the touch screen, we can customize the whole touch panel, such as the color, shape, cover thickness, and so on according to the customer's requirements.
5. Q: Which applications your products are mainly used for?
A: Embedded system, Intercom system, Biometrix, HMI, Smart home, Robert, Hand-held PDA, Aftermarket automotive and etc.
